SRAM Timing Troubles: Decoding the 512 Byte Mystery

Hey everyone! Let's dive into a head-scratcher regarding the timing of a 512-byte SRAM, specifically within the globalfoundries-pdk-ip-gf180mcu_fd_ip_sram repository. While it's noted that this repo might not be actively maintained, the hope is to spark some discussion and potentially find a more active home for it, maybe with the FOSSi Foundation. The main issue revolves around conflicting timing information and understanding which values to trust. So, let's break it down and figure this out together, alright?

Decoding SRAM Timing Discrepancies

When dealing with SRAM timing, it's crucial to have accurate and consistent data. In this case, the documentation indicates that this SRAM is the 5.0V version, utilizing a 180nm 5V Green CMOS 13.5um2 6 transistors bitcell. The AC characteristics for the 5.0V version specify a worst-case cycle time (Tcyc) of 11.8901. This is our starting point, the baseline we expect. But things get interesting when we look at the liberty file.

Delving into the gf180mcu_fd_ip_sram__sram512x8m8wm1__ss_n40C_4v50.lib file, which is supposed to represent the same worst-case scenario, we find a minimum period of 8.183685. This is significantly different from the 11.8901 mentioned in the documentation. The liberty file is supposed to hold the timing information, and if it is not correct, then the IP becomes useless.

Then, if you check gf180mcu_fd_ip_sram__sram512x8m8wm1.v, Tcyc is defined as 55600. This value seems way off compared to the other two. The closest reference point is 56.5713 for the 1.8V - SNSP Process 1.62v, 125C, adding another layer of confusion. So, where do all these numbers come from, and more importantly, which one should be considered reliable?

The million-dollar question: Can we trust the lib file for timing? This is paramount because the liberty file is the standard way timing is conveyed for digital IP blocks like SRAMs. It's used in static timing analysis (STA) to verify that the design meets its timing requirements. If the liberty file is inaccurate, the entire timing analysis is compromised. What are the meanings of these other values? Is there an undocumented 1.8V version? Or are these timing characterizations applicable if the SRAM's voltage drops to 1.8V under certain conditions?

Resolving the Timing Puzzle

Let's dissect this timing conundrum step by step. The first thing we need to address is the discrepancy between the documentation and the liberty file. Usually, the liberty file is the more accurate source of timing information because it's generated from detailed simulations of the SRAM circuit. Documentation can sometimes lag behind the actual characterized performance of the IP.

However, it's not uncommon that there can be errors or typos in the liberty file. So we can't just blindly trust the liberty file. The value of 55600 found in the Verilog file seems completely out of sync with the other timing values, so we should be careful using it.

To ascertain the trustworthiness of the liberty file, a few steps can be taken:

  1. Cross-Verification: Compare the liberty file with other available documentation or characterization reports. Look for any notes or errata that might explain the discrepancy.
  2. Simulation: Run simulations using the liberty file to see if the timing behavior aligns with expectations. This can be done using tools like SPICE or other circuit simulators.
  3. Expert Consultation: Consult with experts who have experience with this particular SRAM IP or with GlobalFoundries' 180nm process. They might have insights into common timing issues or known errata.

Voltage Considerations and Timing

Voltage has a significant impact on the timing characteristics of SRAM. Lowering the voltage generally increases the delay and reduces the operating frequency. This is because the transistors switch slower at lower voltages. The reference to 1.8V raises a few possibilities:

  • Multiple Voltage Versions: There might be a 1.8V version of the SRAM that's not explicitly included in the documentation. This is less likely but still possible.
  • Low-Voltage Characterization: The SRAM might have been characterized at 1.8V to understand its behavior under extreme conditions. This information could be useful for power management or fault analysis.
  • Process Corner Effects: The timing values might represent the worst-case scenario when the SRAM is operating at 1.8V and experiencing other process variations, such as high temperature or slow transistors.

To clarify the voltage dependency, it's essential to consult the characterization reports or run simulations at different voltage levels. This will help understand how the timing changes with voltage and identify the worst-case operating conditions.

Community Input and Potential Solutions

Given the uncertainty around the maintenance of the repository, here are a few avenues to explore to resolve this timing puzzle and ensure the continued usability of this valuable IP:

Engaging with the Community

  • FOSSi Foundation: As initially suggested, moving the repository to an organization like the FOSSi Foundation could provide a more active maintenance environment. FOSSi (Free and Open Source Silicon Foundation) is dedicated to supporting and promoting open-source hardware projects. They have the infrastructure and community to ensure the IP remains up-to-date and accurate.
  • Open Source Forums: Post the issue on open-source hardware forums or mailing lists. There might be other users who have encountered similar timing issues and can offer insights or solutions.
  • GitHub Issues: Create a detailed issue on the GitHub repository, outlining the timing discrepancies and the steps taken to investigate them. This will help attract the attention of other users and potential maintainers.

Investigating Further

  • Contacting GlobalFoundries: If possible, reach out to GlobalFoundries directly to inquire about the timing characteristics of the SRAM. They might be able to provide additional documentation or clarification.
  • Reverse Engineering: As a last resort, consider reverse engineering the SRAM layout to extract the timing parameters. This is a time-consuming and complex process, but it can provide valuable insights into the SRAM's behavior.

Potential Pitfalls and Considerations

  • Process Variations: Remember that timing can vary significantly due to process variations. The values in the liberty file are typically based on worst-case process corners, but actual silicon may perform differently.
  • Temperature Effects: Temperature also affects timing. Higher temperatures generally increase delays. Make sure to consider the operating temperature range when analyzing timing.
  • Layout Effects: The layout of the SRAM can also impact timing. Parasitic capacitances and inductances can add delays. Extracting the layout and simulating it can provide more accurate timing information.

Conclusion: Trust, But Verify

In summary, the conflicting timing values for the 512-byte SRAM in the globalfoundries-pdk-ip-gf180mcu_fd_ip_sram repository present a challenge. While the liberty file is generally the most reliable source of timing information, it's crucial to verify its accuracy through cross-verification, simulation, and expert consultation. Understanding the impact of voltage, temperature, and process variations on timing is also essential.

By engaging with the community, exploring potential solutions, and carefully considering the various factors that can affect timing, we can hopefully resolve this timing puzzle and ensure the continued usability of this valuable IP. Keep digging, keep questioning, and let's get to the bottom of this together! And of course, hopefully we can find a new home for this repo where it can get the love and attention it deserves!
