JVB Autoscaler with Single External IP in Kubernetes

Let's dive into configuring JVB (Jitsi Video Bridge) autoscaler with just one external IP address in a Kubernetes (k8s) environment. This setup is common when you're using ingress and the jvb-autoscaler to manage your JVB instances. When the load balancer creates new pods and nodes on demand, these nodes typically get assigned random external IPs from your provider, which isn't ideal. You want all UDP traffic to go through a single, predictable IP. Here’s how we can tackle this!

Understanding the Challenge

When you deploy Jitsi in Kubernetes and use the jvb-autoscaler, the autoscaler spins up new JVB pods and nodes as needed based on the load. Each of these nodes gets an external IP address. Participants connecting to your Jitsi instance send UDP traffic to these JVB instances, using the external IP address of the node hosting it. The main challenge is that these external IP addresses are often dynamically assigned and can change, making it difficult to manage firewall rules, DNS configurations, and overall network stability. The goal is to consolidate all UDP traffic to a single external IP, typically the one associated with your ingress controller.

Potential Solutions and Strategies

There are several approaches to ensure all UDP traffic goes through a single external IP address. Let's explore these in detail.

1. Using the Ingress Controller's External IP

The most straightforward approach would be to route all UDP traffic through the ingress controller's external IP. However, ingress controllers are typically designed for HTTP/HTTPS traffic and don't handle UDP traffic natively. Here’s how you can explore this option:

  • LoadBalancer Service: Instead of using an ingress, you can expose your JVB pods using a LoadBalancer type service. This service is associated with a single external IP provided by your cloud provider. The downside is that each JVB instance will get its own LoadBalancer, which is not cost-effective.
  • NodePort with External Load Balancer: Configure your JVB service as NodePort and then set up an external load balancer (like HAProxy or Nginx) that forwards UDP traffic to the nodes on the specified NodePort. This load balancer will have a static external IP address.

To implement the NodePort approach, you would:

  1. Set the JVB service type to NodePort in your Helm chart.
  2. Configure an external load balancer to forward UDP traffic to the nodes on the specified NodePort.

2. Centralized UDP Proxy

Another approach is to set up a centralized UDP proxy that listens on a single external IP and forwards traffic to the appropriate JVB instances. This can be achieved using tools like:

  • HAProxy: A high-performance load balancer that can handle UDP traffic.
  • Nginx: With the UDP module, Nginx can also act as a UDP proxy.
  • Custom UDP Proxy: You can write a simple UDP proxy using languages like Go or Python.

Here’s how you can set up a centralized UDP proxy using HAProxy:

  1. Deploy HAProxy: Deploy HAProxy in your Kubernetes cluster.
  2. Configure HAProxy: Configure HAProxy to listen on the desired external IP and forward UDP traffic to the JVB instances. You'll need to configure HAProxy to balance the load across the JVB instances based on their current load and availability.
  3. Update JVB Configuration: Update the JVB configuration to use the internal IP of the HAProxy service as the STUN server.

3. Kubernetes Network Policies and Static IPs

Ensure that your Kubernetes network policies allow UDP traffic between the nodes and pods. If you can reserve static IPs from your cloud provider, you could assign them to the nodes running JVB. However, this approach doesn't scale well with autoscaling.

Here’s how you can use network policies:

  1. Define Network Policies: Create Kubernetes network policies that allow UDP traffic between the JVB pods and other necessary services.
  2. Apply Network Policies: Apply the network policies to your Kubernetes cluster.

4. JVB Configuration Adjustments

Review your JVB configuration to ensure it's optimized for your environment. Some key parameters to consider include:

  • STUN/TURN Servers: Ensure that your STUN/TURN servers are correctly configured and accessible.
  • Port Ranges: Configure the UDP port ranges used by JVB to avoid conflicts.
  • Max Bitrate: Set the maximum bitrate for the JVB instances to prevent overloading the network.

Here’s an example of JVB configuration in your Helm chart:

jvb:
  image:
    repository: jitsi/jvb
  nodePort: 31100
  service:
    type: ClusterIP
  useHostPort: true
  useNodeIP: true
  stunServers: "stun.hostname.tld:443"

5. Leveraging MetalLB for On-Premise Clusters

If you're running your Kubernetes cluster on-premise, you can use MetalLB to provide a load balancer with a static IP address. MetalLB integrates with your network to assign an IP address to a service, allowing you to expose your JVB instances using a stable IP.

Here’s how to set up MetalLB:

  1. Install MetalLB: Install MetalLB in your Kubernetes cluster.
  2. Configure MetalLB: Configure MetalLB with a range of IP addresses to use for load balancing.
  3. Expose JVB Service: Expose your JVB service using the LoadBalancer type. MetalLB will automatically assign an IP address to the service.

6. Cloud Provider Specific Solutions

Each cloud provider (AWS, Azure, GCP) offers its own load balancing solutions. These solutions often allow you to configure a static external IP address. For example:

  • AWS: Use an Elastic Load Balancer (ELB) or Network Load Balancer (NLB) with a static IP.
  • Azure: Use an Azure Load Balancer with a static public IP address.
  • GCP: Use a Google Cloud Load Balancer with a static external IP address.

Here’s an example of using a Network Load Balancer (NLB) on AWS:

  1. Create NLB: Create a Network Load Balancer in your AWS account.
  2. Configure NLB: Configure the NLB to forward UDP traffic to your JVB instances.
  3. Associate Static IP: Associate a static Elastic IP address with the NLB.

Detailed Steps and Configuration Examples

Let’s walk through a detailed example of setting up a centralized UDP proxy using HAProxy in a Kubernetes environment.

Step 1: Deploy HAProxy in Kubernetes

First, you'll need to deploy HAProxy in your Kubernetes cluster. You can use a deployment and a service to manage the HAProxy pods.

apiVersion: apps/v1
kind: Deployment
metadata:
  name: haproxy-deployment
spec:
  replicas: 1
  selector:
    matchLabels:
      app: haproxy
  template:
    metadata:
      labels:
        app: haproxy
    spec:
      containers:
      - name: haproxy
        image: haproxy:latest
        ports:
        - containerPort: 5140
          name: udp-port
        volumeMounts:
        - mountPath: /usr/local/etc/haproxy
          name: haproxy-config
      volumes:
      - name: haproxy-config
        configMap:
          name: haproxy-config
---
apiVersion: v1
kind: Service
metadata:
  name: haproxy-service
spec:
  type: LoadBalancer
  selector:
    app: haproxy
  ports:
  - protocol: UDP
    port: 5140
    targetPort: udp-port
    name: udp-port

Step 2: Configure HAProxy

Next, you'll need to configure HAProxy to listen on the desired external IP and forward UDP traffic to the JVB instances. Create a ConfigMap to store the HAProxy configuration.

apiVersion: v1
kind: ConfigMap
metadata:
  name: haproxy-config
data:
  haproxy.cfg: |
    global
      log /dev/log local0
      log /dev/log local1 notice
      chroot /var/lib/haproxy
      stats socket /run/haproxy/admin.sock mode 660 level admin
      stats timeout 30s
      user haproxy
      group haproxy
      daemon

    defaults
      log global
      mode http
      option httplog
      option dontlognull
      timeout connect 5000
      timeout client  50000
      timeout server  50000
      retries 3
      option redispatch
      maxconn 2000

    frontend jvb-udp
      bind *:5140 udp
      default_backend jvb-servers

    backend jvb-servers
      mode udp
      balance roundrobin
      server jvb-1 <jvb-1-ip>:10000 check
      server jvb-2 <jvb-2-ip>:10000 check

Replace <jvb-1-ip> and <jvb-2-ip> with the internal IPs of your JVB instances. Also, ensure that the port 10000 matches the UDP port used by your JVB instances.

Step 3: Update JVB Configuration

Update the JVB configuration to use the internal IP of the HAProxy service as the STUN server. This will ensure that all UDP traffic from the JVB instances is routed through the HAProxy service.

jvb:
  image:
    repository: jitsi/jvb
  nodePort: 31100
  service:
    type: ClusterIP
  useHostPort: true
  useNodeIP: true
  stunServers: "<haproxy-service-ip>:5140"

Replace <haproxy-service-ip> with the internal IP of the HAProxy service.

Step 4: Apply the Configurations

Apply the deployment, service, and ConfigMap to your Kubernetes cluster.

kubectl apply -f haproxy-deployment.yaml
kubectl apply -f haproxy-service.yaml
kubectl apply -f haproxy-config.yaml

Conclusion

Configuring JVB autoscaler with a single external IP address in Kubernetes requires careful planning and execution. By using a centralized UDP proxy like HAProxy, leveraging cloud provider-specific load balancing solutions, or using MetalLB for on-premise clusters, you can ensure that all UDP traffic is routed through a single, stable IP address. Remember to consider the scalability and cost implications of each approach before making a final decision. Hope this helps, and good luck setting up your JVB autoscaler!
