Istio Gateway-API NodePort Access Issue On AWS

Hey guys,

I'm diving into the world of Istio and Gateway-API, and I've hit a snag. I'm trying to set up an AWS Load Balancer Controller to work with an Istio gateway, using the Gateway API. The setup involves a NodePort service, but I'm facing an issue where I can only access the gateway pod on the host of the pod itself. Accessing it from other hosts results in the port being closed. I'm hoping someone in the Istio community can lend a hand!

Understanding the Setup and the Problem

Istio and Gateway API are powerful tools for managing traffic in a Kubernetes environment. The Gateway API provides a more expressive and flexible way to configure ingress compared to the older Ingress resources. In this specific scenario, I'm using an AWS Load Balancer to direct traffic to an Istio gateway. The Istio gateway is exposed via a NodePort service. However, the problem arises when trying to access the gateway's NodePort from any node other than the one where the gateway pod is running. I am currently running this setup on AWS.

The Configuration Details

Here's a breakdown of the configurations I've put together:

• Gateway Resource: The Gateway resource is defined in the gateway namespace and uses the istio gateway class. The service type is set to NodePort, and it listens on port 80 for HTTP traffic.

apiVersion: gateway.networking.k8s.io/v1
kind: Gateway
metadata:
  name: general-gateway
  namespace: gateway
  annotations:
    networking.istio.io/service-type: NodePort
spec:
  gatewayClassName: istio
  listeners:
    - name: http
      port: 80
      protocol: HTTP
      allowedRoutes:
        namespaces:
          from: All

• Service Resource: A Service of type NodePort is created to expose the Gateway. The externalTrafficPolicy is set to Cluster.

apiVersion: v1
kind: Service
metadata:
  annotations:
    argocd.argoproj.io/tracking-id: gateway:gateway.networking.k8s.io/Gateway:gateway/general-gateway
    networking.istio.io/service-type: NodePort
  creationTimestamp: "2025-11-12T09:42:29Z"
  labels:
    gateway.istio.io/managed: istio.io-gateway-controller
    gateway.networking.k8s.io/gateway-name: general-gateway
    istio.io/dataplane-mode: none
  name: general-gateway-istio
  namespace: gateway
  ownerReferences:
  - apiVersion: gateway.networking.k8s.io/v1beta1
    kind: Gateway
    name: general-gateway
    uid: 8227496b-5a66-478f-84b0-b0c1c3cfaebe
  resourceVersion: "6565369"
  uid: a8d82d17-d28c-4c57-afbb-43a1245e5dbf
spec:
  clusterIP: 172.20.18.246
  clusterIPs:
  - 172.20.18.246
  externalTrafficPolicy: Cluster
  internalTrafficPolicy: Cluster
  ipFamilies:
  - IPv4
  ipFamilyPolicy: PreferDualStack
  ports:
  - appProtocol: tcp
    name: status-port
    nodePort: 30667
    port: 15021
    protocol: TCP
    targetPort: 15021
  - appProtocol: http
    name: http
    nodePort: 32549
    port: 80
    protocol: TCP
    targetPort: 80
  selector:
    gateway.networking.k8s.io/gateway-name: general-gateway
  sessionAffinity: None
  type: NodePort
status:
  loadBalancer: {}

• Pod Resource: The Istio proxy is injected as a sidecar in the pod. The pod has various configurations related to Istio proxy settings.

apiVersion: v1
kind: Pod
metadata:
  annotations:
    argocd.argoproj.io/tracking-id: gateway:gateway.networking.k8s.io/Gateway:gateway/general-gateway
    istio.io/rev: default
    networking.istio.io/service-type: NodePort
    prometheus.io/path: /stats/prometheus
    prometheus.io/port: "15020"
    prometheus.io/scrape: "true"
  creationTimestamp: "2025-11-12T09:42:29Z"
  generateName: general-gateway-istio-7c6fd54c6d-
  generation: 1
  labels:
    gateway.istio.io/managed: istio.io-gateway-controller
    gateway.networking.k8s.io/gateway-name: general-gateway
    istio.io/dataplane-mode: none
    pod-template-hash: 7c6fd54c6d
    service.istio.io/canonical-name: general-gateway-istio
    service.istio.io/canonical-revision: latest
    sidecar.istio.io/inject: "false"
  name: general-gateway-istio-7c6fd54c6d-rnkg7
  namespace: gateway
  ownerReferences:
  - apiVersion: apps/v1
    blockOwnerDeletion: true
    controller: true
    kind: ReplicaSet
    name: general-gateway-istio-7c6fd54c6d
    uid: 01c0dfdd-0ddf-495b-b76a-42152dfe6269
  resourceVersion: "6565433"
  uid: fc14fd0a-a6e0-48ee-92a7-d96d3f2484d9
spec:
  containers:
  - args:
    - proxy
    - router
    - --domain
    - $(POD_NAMESPACE).svc.cluster.local
    - --proxyLogLevel
    - warning
    - --proxyComponentLogLevel
    - misc:error
    - --log_output_level
    - default:info
    env:
    - name: PILOT_CERT_PROVIDER
      value: istiod
    - name: CA_ADDR
      value: istiod.istio-system.svc:15012
    - name: POD_NAME
      valueFrom:
        fieldRef:
          apiVersion: v1
          fieldPath: metadata.name
    - name: POD_NAMESPACE
      valueFrom:
        fieldRef:
          apiVersion: v1
          fieldPath: metadata.namespace
    - name: INSTANCE_IP
      valueFrom:
        fieldRef:
          apiVersion: v1
          fieldPath: status.podIP
    - name: SERVICE_ACCOUNT
      valueFrom:
        fieldRef:
          apiVersion: v1
          fieldPath: spec.serviceAccountName
    - name: HOST_IP
      valueFrom:
        fieldRef:
          apiVersion: v1
          fieldPath: status.hostIP
    - name: ISTIO_CPU_LIMIT
      valueFrom:
        resourceFieldRef:
          divisor: "0"
          resource: limits.cpu
    - name: PROXY_CONFIG
      value: |
        {"proxyMetadata":{"ISTIO_META_ENABLE_HBONE":"true"},"image":{"imageType":"distroless"}}
    - name: ISTIO_META_POD_PORTS
      value: '[]'
    - name: ISTIO_META_APP_CONTAINERS
    - name: GOMEMLIMIT
      valueFrom:
        resourceFieldRef:
          divisor: "0"
          resource: limits.memory
    - name: GOMAXPROCS
      valueFrom:
        resourceFieldRef:
          divisor: "0"
          resource: limits.cpu
    - name: ISTIO_META_CLUSTER_ID
      value: Kubernetes
    - name: ISTIO_META_NODE_NAME
      valueFrom:
        fieldRef:
          apiVersion: v1
          fieldPath: spec.nodeName
    - name: ISTIO_META_INTERCEPTION_MODE
      value: REDIRECT
    - name: ISTIO_META_WORKLOAD_NAME
      value: general-gateway-istio
    - name: ISTIO_META_OWNER
      value: kubernetes://apis/apps/v1/namespaces/gateway/deployments/general-gateway-istio
    - name: ISTIO_META_MESH_ID
      value: cluster.local
    - name: TRUST_DOMAIN
      value: cluster.local
    - name: ISTIO_META_ENABLE_HBONE
      value: "true"
    image: docker.io/istio/proxyv2:1.27.2-distroless
    imagePullPolicy: IfNotPresent
    name: istio-proxy
    ports:
    - containerPort: 15020
      name: metrics
      protocol: TCP
    - containerPort: 15021
      name: status-port
      protocol: TCP
    - containerPort: 15090
      name: http-envoy-prom
      protocol: TCP
    readinessProbe:
      failureThreshold: 4
      httpGet:
        path: /healthz/ready
        port: 15021
        scheme: HTTP
      periodSeconds: 15
      successThreshold: 1
      timeoutSeconds: 1
    resources:
      limits:
        cpu: "2"
        memory: 1Gi
      requests:
        cpu: 100m
        memory: 128Mi
    securityContext:
      allowPrivilegeEscalation: false
      capabilities:
        drop:
        - ALL
      privileged: false
      readOnlyRootFilesystem: true
      runAsGroup: 1337
      runAsNonRoot: true
      runAsUser: 1337
    startupProbe:
      failureThreshold: 30
      httpGet:
        path: /healthz/ready
        port: 15021
        scheme: HTTP
      initialDelaySeconds: 1
      periodSeconds: 1
      successThreshold: 1
      timeoutSeconds: 1
    terminationMessagePath: /dev/termination-log
    terminationMessagePolicy: File
    volumeMounts:
    - mountPath: /var/run/secrets/workload-spiffe-uds
      name: workload-socket
    - mountPath: /var/run/secrets/credential-uds
      name: credential-socket
    - mountPath: /var/run/secrets/workload-spiffe-credentials
      name: workload-certs
    - mountPath: /var/run/secrets/istio
      name: istiod-ca-cert
    - mountPath: /var/lib/istio/data
      name: istio-data
    - mountPath: /etc/istio/proxy
      name: istio-envoy
    - mountPath: /var/run/secrets/tokens
      name: istio-token
    - mountPath: /etc/istio/pod
      name: istio-podinfo
    - mountPath: /var/run/secrets/kubernetes.io/serviceaccount
      name: kube-api-access-86hr9
      readOnly: true
  dnsPolicy: ClusterFirst
  enableServiceLinks: true
  nodeName: ip-10-0-38-213.us-west-2.compute.internal
  preemptionPolicy: PreemptLowerPriority
  priority: 0
  restartPolicy: Always
  schedulerName: default-scheduler
  securityContext:
    sysctls:
    - name: net.ipv4.ip_unprivileged_port_start
      value: "0"
  serviceAccount: general-gateway-istio
  serviceAccountName: general-gateway-istio
  terminationGracePeriodSeconds: 30
  tolerations:
  - effect: NoExecute
    key: node.kubernetes.io/not-ready
    operator: Exists
    tolerationSeconds: 300
  - effect: NoExecute
    key: node.kubernetes.io/unreachable
    operator: Exists
    tolerationSeconds: 300
  volumes:
  - emptyDir: {}
    name: workload-socket
  - emptyDir: {}
    name: credential-socket
  - emptyDir: {}
    name: workload-certs
  - emptyDir:
      medium: Memory
    name: istio-envoy
  - emptyDir: {}
    name: istio-data
  - downwardAPI:
      defaultMode: 420
      items:
      - fieldRef:
          apiVersion: v1
          fieldPath: metadata.labels
        path: labels
      - fieldRef:
          apiVersion: v1
          fieldPath: metadata.annotations
        path: annotations
    name: istio-podinfo
  - name: istio-token
    projected:
      defaultMode: 420
      sources:
      - serviceAccountToken:
          audience: istio-ca
          expirationSeconds: 43200
          path: istio-token
  - configMap:
      defaultMode: 420
      name: istio-ca-root-cert
    name: istiod-ca-cert
  - name: kube-api-access-86hr9
    projected:
      defaultMode: 420
      sources:
      - serviceAccountToken:
          expirationSeconds: 3607
          path: token
      - configMap:
          items:
          - key: ca.crt
            path: ca.crt
          name: kube-root-ca.crt
      - downwardAPI:
          items:
          - fieldRef:
              apiVersion: v1
              fieldPath: metadata.namespace
            path: namespace
status:
  conditions:
  - lastProbeTime: null
    lastTransitionTime: "2025-11-12T09:42:30Z"
    status: "True"
    type: PodReadyToStartContainers
  - lastProbeTime: null
    lastTransitionTime: "2025-11-12T09:42:29Z"
    status: "True"
    type: Initialized
  - lastProbeTime: null
    lastTransitionTime: "2025-11-12T09:42:32Z"
    status: "True"
    type: Ready
  - lastProbeTime: null
    lastTransitionTime: "2025-11-12T09:42:32Z"
    status: "True"
    type: ContainersReady
  - lastProbeTime: null
    lastTransitionTime: "2025-11-12T09:42:29Z"
    status: "True"
    type: PodScheduled
  containerStatuses:
  - allocatedResources:
      cpu: 100m
      memory: 128Mi
    containerID: containerd://262658ab1e4e81ce6aa6a64d031bb6af2f7f2febfdbd762abe2b2c3f4d7529d5
    image: docker.io/istio/proxyv2:1.27.2-distroless
    imageID: docker.io/istio/proxyv2@sha256:91dfb31791224e6cc4a2e4b4050a148b0bae3c7e0d5fb56e2de1a417e4b39cce
    lastState: {}
    name: istio-proxy
    ready: true
    resources:
      limits:
        cpu: "2"
        memory: 1Gi
      requests:
        cpu: 100m
        memory: 128Mi
    restartCount: 0
    started: true
    state:
      running:
        startedAt: "2025-11-12T09:42:30Z"
    user:
      linux:
        gid: 1337
        supplementalGroups:
        - 1337
        uid: 1337
    volumeMounts:
    - mountPath: /var/run/secrets/workload-spiffe-uds
      name: workload-socket
    - mountPath: /var/run/secrets/credential-uds
      name: credential-socket
    - mountPath: /var/run/secrets/workload-spiffe-credentials
      name: workload-certs
    - mountPath: /var/run/secrets/istio
      name: istiod-ca-cert
    - mountPath: /var/lib/istio/data
      name: istio-data
    - mountPath: /etc/istio/proxy
      name: istio-envoy
    - mountPath: /var/run/secrets/tokens
      name: istio-token
    - mountPath: /etc/istio/pod
      name: istio-podinfo
    - mountPath: /var/run/secrets/kubernetes.io/serviceaccount
      name: kube-api-access-86hr9
      readOnly: true
      recursiveReadOnly: Disabled
  hostIP: 10.0.38.213
  hostIPs:
  - ip: 10.0.38.213
  phase: Running
  podIP: 10.0.43.141
  podIPs:
  - ip: 10.0.43.141
  qosClass: Burstable
  startTime: "2025-11-12T09:42:29Z"

The Versions

Here are the versions I'm using:

• istioctl version: Client version: 1.28.0, Control plane version: 1.27.2, Data plane version: 1.27.2 (9 proxies)
• kubectl version: Client Version: v1.32.1, Kustomize Version: v5.5.0, Server Version: v1.33.5-eks-ba24e9c

Troubleshooting Steps and Initial Thoughts

NodePort services are designed to make an application accessible on a static port on each node in your cluster. When you access a NodePort from outside the cluster, the traffic is routed to the corresponding pod. In the case of Istio and Gateway API, the expectation is that the traffic should be routed to the gateway pod, regardless of which node the request hits. Since it's only working on the host of the pod, it seems like there might be a problem with the network configuration or the way Istio is handling the traffic routing.

Here's what I've tried and what I'm thinking might be the issue:

1. Network Policies: Checked if any network policies are interfering with the traffic flow. Ensure that traffic is allowed to the NodePort on all nodes.
2. AWS Security Groups and NACLs: Validated that the security groups and network ACLs on AWS are correctly configured to allow traffic to the NodePort from all the necessary sources (e.g., the Load Balancer Controller).
3. externalTrafficPolicy: The externalTrafficPolicy on the service is set to Cluster. This setting can influence how traffic is routed. With Cluster, the traffic is routed to a node, and then the kube-proxy handles forwarding the traffic to the gateway pod. However, it is set to Cluster, which should not cause this behaviour. I've considered switching to Local and checking if that resolves the problem. When set to Local, it ensures that traffic is only routed to pods running on the same node.
4. Istio Proxy Configuration: Checked the Istio proxy logs for any errors or warnings related to routing or traffic handling. Ensured the proxy is configured correctly and has the necessary permissions.
5. Gateway API Configuration: Reviewed the Gateway API configuration to make sure it correctly specifies the port and protocol. Also, I've confirmed that the gatewayClassName is set correctly.
6. iptables Rules: Checked the iptables rules on the nodes. This might give some insight if there are any rules blocking or redirecting the traffic.

Potential Causes and Solutions

Let's brainstorm some potential causes and possible solutions:

1. Incorrect Network Configuration

• Problem: Misconfigured AWS security groups, NACLs, or Kubernetes network policies might be blocking traffic to the NodePort on nodes other than the one running the pod.
• Solution: Double-check AWS security group and NACL rules to ensure they allow inbound traffic to the NodePort (e.g., 32549) from the CIDR blocks of your AWS Load Balancer Controller. Review Kubernetes network policies to ensure they are not blocking traffic to the service.

2. externalTrafficPolicy Misconfiguration

• Problem: Although the externalTrafficPolicy is set to Cluster, which should work, there might be some interaction with the AWS environment that is causing unexpected behaviour. Cluster means that traffic can be forwarded to any node in the cluster.
• Solution: Try setting the externalTrafficPolicy to Local and see if it makes a difference. This setting could potentially help to rule out routing issues. Keep in mind that with Local, the traffic will only be routed to the pods running on that node. If the service is still not accessible from other nodes, it might indicate a more fundamental networking problem.

3. Istio Proxy Issues

• Problem: There could be issues within the Istio proxy itself. The proxy might not be configured correctly or might be failing to route traffic as expected.
• Solution: Check the Istio proxy logs (istio-proxy container logs) for any errors. Also, check the Envoy configuration to ensure it has the correct routes and listeners. This can be done by accessing the Envoy admin interface. Verify that the proxy is properly receiving the configuration from Istiod.

4. Incorrect Gateway API Configuration

• Problem: A misconfiguration in the Gateway API resources can also lead to traffic routing problems. Incorrect port, protocol, or route specifications could cause the issue.
• Solution: Double-check the Gateway and HTTPRoute resources. Make sure the port, protocol, and allowed routes are correctly configured. Ensure the gatewayClassName matches the Istio gateway class. Use kubectl describe gateway <gateway-name> -n <namespace> to examine the status of the Gateway resource and confirm it's ready.

5. AWS Load Balancer Controller Integration

• Problem: There might be an issue with how the AWS Load Balancer Controller interacts with Istio and the NodePort service.
• Solution: Make sure you're using a compatible version of the AWS Load Balancer Controller. Verify that the controller is correctly provisioning the load balancer and that the load balancer is properly configured to route traffic to the NodePort. Examine the logs of the AWS Load Balancer Controller for any errors or warnings. Also, check the annotations on the service to make sure the load balancer is configured correctly.

Seeking Community Help

Guys, I've tried a few things, but I'm still stuck. Any insights or suggestions from the community would be greatly appreciated! If anyone has encountered a similar issue or has any ideas, please share them. Any advice would be a great help!

Thanks in advance for your assistance!
